Sustainable Drainage for a Better Tomorrow.
Imptrex® Drain Cell is a light weight, high strength modular drainage cell designed primarily for sub-surface drainage. It is manufactured from high strength recycled polypropylene and used in the construction of roof gardens, plaza decks, basements, concealed drains, planter boxes and sportfields.
It is designed to withstand heavy loads imposed by mechanical equipment's. Available in 20 mm and 30 mm high modules. Imptrex® Drain Cell modules interlock in the same plane and at right angles to one another.
| Product | DRAIN CELL - 20mm |
|---|---|
| Material | Recycled polypropylene |
| Dimensions | 500 mm x 250 mm |
| Height | 20 mm |
| Weight | 2.5–3 kg/sqm |
| Surface Void Area | 67% |
| Internal Void Area | 92% |
| Compressive Strength | 100 tons/sqm |
| Drainage Capacity @ 1% | 12.5 l/m.s |
| Product | DRAIN CELL - 30 mm |
|---|---|
| Material | Recycled polypropylene |
| Dimensions | 500 mm x 250 mm |
| Height | 30 mm |
| Weight | 2.5–3 kg/sqm |
| Surface Void Area | 67% |
| Internal Void Area | 92% |
| Compressive Strength | 140 tons/sqm |
| Drainage Capacity @ 1% | 16.5 l/m.s |
